Description
Compact Case, Unlimited Creativity
QUBE 540
Designed for creators, gamers, and DIY builders.
Model Number Stardust Iron: Q540-MGNN-S00
Model Number Moonstone: Q540-LGNN-S00
Color(s)Stardust Iron / Moonstone
Materials - ExteriorSteel
Material - Side Panel (Right)Steel
Material - Side Panel (Left)TG
Dimensions (L x W x H)Incl. Protrusions: 438.5 x 225 x 492.1 mm
Dimensions (L x W x H)Excl. Protrusions: 425 x 225 x 425 mm
Volume (w/o protrusions)40.64 L
Volume (with panel, protrusions and feet)48.55 L
Motherboard SupportITX / M-ATX / ATX / *E-ATX (*Up to 280 mm)
Drive Bays - 5.25" ODDN/A
Drive Bays - 3.5" HDD1 (Shared 3.5" and 2.5" mounting on PSU bracket)
Drive Bays - 2.5" SSD2 (Max. 5)
I/O Panel - USB Ports2 x USB 3.2 Gen 1 Type A / 1 x USB 3.2 Gen 2 x 2 Type C
I/O Panel - Audio In / Out1 x 3.5 Mic / Audio Combo Jack
Fan Support - Front3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Fan Support - Top3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Fan Support - Rear1x 120mm
Fan Support - Bottom3 x 120 mm / 2 x 140 mm
Preinstalled Fan(s) - FrontN/A
Preinstalled Fan(s) - TopN/A
Pre-installed Fans - Rear1x 120mm Black Fan
Radiator Support - Front140 / 280 / 360 mm (w/o I/O panel)
Radiator Support - Top140 / 280 / 360 mm (w/o I/O panel)
Radiator Support - Rear120 mm
Radiator Support - Bottom140 / 280 / 360mm (w/o I/O panel)
Clearances - CPU Cooler172 mm
Clearances - Power Supply200 mm
Clearances - Graphics Card415 mm (w/o Front Fan)
Cable Routing - Behind Motherboard Tray27 mm
Dust FiltersTop / Bottom / Front
Power Supply SupportATX / SFX
