Description
Power Evolved
MWE Bronze 650 V3 230V
- ATX 3.1 support
- High temperature resilience
- Quiet HDB fan
- 80 Plus Bronze certified efficiency
- Embossed cable
- 5-year warranty
ATX 3.1 Support
Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, this unit is ideal for use with the 40 series GPUs.
*All performance stats confirmed in 25°C ambient temperature testing.
Embossed Cable
An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.
Quiet HDB Fan
A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.
*All performance stats confirmed in 25°C ambient temperature testing.
Certified Efficiency
Certified Efficiency
The MWE Bronze V3 230V is certified to achieve more than 88% efficiency at typical loads.
*All performance stats confirmed in 25°C ambient temperature testing.
High Temperature Resilience
High Temperature Resilience
A 40°C operating temperature allows for pushing your machine to the limits.
*All performance stats confirmed in 25°C ambient temperature testing.
PSU Calculator
Need help choosing the right power supply for your system? Try out our comprehensive and easy-to-use PSU calculator.
PSU Calculator
Specifications
| Model |
MPE-6501-ACABW-3B |
| ATX Version |
ATX 12V Ver. 3.1 |
| PFC |
Active PFC |
| Input Voltage |
200-240V |
| Input Current |
5A |
| Input Frequency |
50-60Hz |
| Dimensions (L x W x H) |
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch |
| Fan Size |
120mm |
| Fan Bearing |
HDB |
| Efficiency |
>88% @ Typical Load |
| 80 PLUS Rating |
80 PLUS Bronze EU 230V |
| ErP 2014 Lot 3 |
Yes |
| Operating Temperature |
0-40°C |
| Power Good Signal |
100 - 150 ms |
| Hold Up Time |
>16ms |
| MTBF |
>100,000 Hours |
| Protections |
UVP / OVP / OPP / OTP / SCP |
| Regulatory |
TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.) |
| ATX 24 Pin Connectors |
1 |
| EPS 8 Pin / 4+4 Pin Connectors |
2 |
| SATA Connectors |
6 |
| Peripheral 4 Pin Connectors |
3 |
| PCI-e 6+2 Pin Connectors |
4 |
| Warranty |
5 Years |
| Series |
MWE Bronze Series |
| Category |
500 to 750W |
| Modular |
Non Modular |
| 80 Plus Efficiency |
Bronze |
| Form Factor |
ATX |
| Watts |
650W |
